Specifications
Synth voice features
- 6 × FM-based Machines
- 1 × Assignable LFO per track
- 1 × Assignable velocity modulation per track
- Storage space for up to 60,000 presets
Sequencer
- 6 × Audio tracks (all of which may be used as MIDI tracks as well)
- Elektron sequencer with up to 64 steps
- Unique length and scale settings per track
- Parameter locks
- Micro timing
- Trig conditions
- Assignable retrig
- Real-time or grid recording of notes and parameters
- 96 × Projects
- 96 × Patterns per Project
- Send & master effects
- Delay and reverb send FX
Hardware
- 6 × Velocity sensitive pads
- Class compliant USB audio 2.0
- 1 × 1/4” stereo headphone jack
- 2 × 1/4” impedance balanced audio out jacks
- 1 × Hi-speed USB 2.0 Micro B port
- 3.5 mm dual polarity TRS MIDI In, Out/Thru jacks
- 128 × 64 pixel LCD screen
- 48 kHz, 24-bit D/A converters
- Hi-speed USB 2.0 Micro B port
- Power inlet: Center positive 3.5 × 1.35 mm barrel jack, 5 V DC, 1 A
Physical specifications
- W270 × D180 × H39 mm (10.7” × 7.1” × 1.6”) (including knobs and feet)
- Weight: approximately 0.80 kg (1.8 lbs)
Miscellaneous
- 3 year Elektron warranty
- Included in the box
- Power Supply PSU-4
- Micro USB Cable USB-2
- 2 × MIDI adapter (5-pin DIN to 3.5mm TRS minijack)
