- Max output voltage: 2 v 0-to-peak
- Output connector: mono 6.3 mm TS or TRS (balanced) jack
- Output resistance: 100 Ohm
- EXT IN: 1 v 0-to-peak
- EXT IN connector: 6.3 mm TS jack
- HOLD GATE: full HOLD volume +5 V
- HOLD GATE connector: 6.3 mm TS jack
- CV DELAY : unipolar, range of 0 to +5 volt
- CV DELAY connector: 6.3 mm TS jack
- CV VOICES: unipolar, range of 0 to +5 volt
- CV VOICES connector: 6.3 mm TS jack
- Power supply: stabilised, +12 V, 0.2 A, centre positive
- Power Consumption: 2 watt
- Dimensions: 266 x 266 x 62 mm
- Weight (without power supply and packaging): 2.5 kg
